• 2 1/2 In. Stainless Steel Liquid Filled Pressure Gauge With Glycerin 0 to 30 Hg, 1/4 (M) NPT, LM
1 1

The color, size, or style shown in some images may differ from the description. Please carefully check the product description before placing your order.

Topring

2 1/2 In. Stainless Steel Liquid Filled Pressure Gauge With Glycerin 0 to 30 Hg, 1/4 (M) NPT, LM

2 1/2 In. Stainless Steel Liquid Filled Pressure Gauge With Glycerin 0 to 30 Hg, 1/4 (M) NPT, LM

Mfr. Model #

55.608

|

Item #

10566127

|

UNSPSC #

774679556082

Your price

Complete your account to see your prices.
Please fill out the form.

$0.00 $0.00
Sale Sold out

Please contact your JRV advisor for more information

Shipping times are based on information available at the time of ordering and are subject to change.

Product information

• Base Mount (LM)
• Inlet connection: 1/4 (M) NPT
• Operating temperature: -18 to 60°C
• 304 stainless steel housing
• Acrylic lens
• Phosphor bronze drone tube
• Movement: Polished brass surface
• Brass fitting
• Reading accuracy: ±1.6% full scale
• Graduation: PSI in black and kPa in red

Features

  • Base Mount (LM)
  • 304 stainless steel housing
  • Phosphor bronze drone tube
  • Acrylic lens
  • Brass fitting

Specifications

Specifications

With CRN
No
Nominal Diameter
2-1/2 in
Compatible Fluids
Air
Installation Type
Lower Mount (LM)
Inlet Nominal Size (Imperial)
1/4 in
Inlet Connection Gender
Male
Maximum Fluid Temperature
60 °C
Mechanism or Internal Moving Parts Material
Phosphor Bronze; Brass
Reading Accuracy
+-1.6 % Of Full Scale
Operating temperature
-18 to 60°C
Maximum Ambient Operating Temperature
60 °C
Body, Housing or Frame Material
Stainless Steel 304
Reading accuracy
±1.6% full scale
Display Type
Analog
Color
Silver
Inlet Connection Type
Threaded
Inlet connection
1/4 (M) NPT
Movement
Polished brass surface
Graduation
PSI in black and kPa in red
